Features:
- Intel® X540 10 Gigabit (10GbE) Ethernet Controller
- 10G BASE-T Converged Network Adapter Simplifies Migration to 10 GbE
- Offers iSCSI, FCoE, virtualization and flexible port zoning
- PCI Express X8 10Gbps dual port RJ45 Ethernet server network card, is based on Intel X540BT2 chipset, which is used as
- Single-chip networking solution for LAN on Motherboard (LOM) to deliver 10 Gigabit Ethernet (10 GbE) platforms on new servers.
- 10GBASE-T Converged Network Adapters simplify migration to 10 GbE, offering iSCSI, FCoE, virtualization and flexible port zoning.
- Whole data, low cost, low power performance
- 10G Gigabit Ethernet, standard CAT-6a cable with RJ45 connector
- Backward compatibility with existing 1000BASE-T networks simplifies transition to 10GbE
- Flexible I/O virtualization with port zoning and Quality of Service (QoS) for up to 64 virtual ports
- Unified network provides LAN, iSCSI and FCoE in one low cost CNA, industry dual port 10GBASE-T adapter,
- Single chip solution with integrated MAC + PHY
- Intel's reliable and proven 10 Gigabit Ethernet technology
- Intel® Ethernet Converged Network Adapter X540
- Load balancing across multiple CPUs
- Remote Boot iSCSI and FCoE
- Supports most network operating systems (NOS)
- RoHS compliant lead-free technology
Specifications:
- Applicable network: 10 Gigabit Ethernet server
- Main Controller: Intel(R) X540
- Bus Type: PCI Express X8, 5.0GT/s
- Media interface: RJ45, copper cable
- Transmission rate: 100/1000/10000Mbps
- Network topology: IEEE 802.3an/ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP)
- IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3au, IEEE 802.3Qbg
- Network/Transport Protocol: TCP/IP, UDP/IP, IPSec, iSCS
- Management functions: IPMI pass-through via SMBus or NC-SI, iSCSI boot, WoL, PXE remote boot, VLAN filtering
- Operating System: FreeBSD, Linux , VMWare ESXi,
- Win 7/ Server2012/ Server 2008/ Win 8/Win 8.1/Server 2016/Win 10
- firmware environment
- Product Certification: FCC, CE, RoHS
- Operating temperature: 0 ~ 55 ℃ (32 ~ 131℉)
- Storage temperature: -40 ~ 70 ℃ (-40 ~ 158 ℉)
- Storage humidity: 90% non-condensing relative humidity at 35°C
Package List：
- 1 x X540 PCIe 10G server network card
- 1 x User Manual
- 1 x Driver-CD
- 1 x short iron piece (optional, suitable for 2U small case)
Packed safely in Retail box.
